323-801-010-003K - Temperature Sender - +50°C to +150°C - M12X1.5

Name: 323-801-010-003K - Temperature Sender - +50°C to +150°C - M12X1.5
SKU: 323-801-010-003K
Availability: InStock

Manufacturer: Continental

Temperature Sender - +50°C to +150°C - Thread M12X1.5

SKU: 323-801-010-003K

Manufacturer part number: 323-801-010-003K

SKU : 323-801-010-003K
Brand : Continental
Product Portfolio : Switches & Senders
Product Family : Senders
Product Group : Temperature Senders
Thread : M12 X 1.5
Temperature Measuring Range : +50°C to +150°C
Sender Resistance Range : 322.8 Ohm to 18.6 Ohm
Sensor Signal : 1 Pole Common Ground
Warning Contact : No Warning Contact
Optional Warning Contact : VDO A2C59510886 Makepoint Switch
Minimum - Maximum Operating Temperature : -40°C to +180°C
Temperature Sender Connector : AMP Male T-model 6.3 x 0.8mm
Sender Element Length + Thread (L) : 22mm
Sensor Diameter : 6.9mm
Torque : 15 Nm
Temperature Medium : Coolant - Water - Air - Engine Oil - Transmission Oil - Fuel
Operating Voltage : 6 - 24 V DC
Weight : 0.5kg
Warranty : 12 Months
