Picture of 2A1/26775TTI - Diaphragm Pump in Polypropylene and AISI 316 Stainless Steel Series PPIB-1

2A1/26775TTI - Diaphragm Pump in Polypropylene and AISI 316 Stainless Steel Series PPIB-1

Manufacturer: Raasm
Diaphragm Pump in Polypropylene and AISI 316 Stainless Steel Series PPIB-1 with Membranes in Teflon® and Hytrel®, balls in Teflon® and seats in AISI 316 stainless steel
SKU: 2A1/26775TTI
Manufacturer part number: 2A1/26775TTI
  • SKU : 2A1/26775TTI
  • Brand : Raasm
  • Product Portfolio : Fluid Handling
  • Product Family : Accessories & Spares
  • Product Group : Other Accessories
  • Product Class : Other Fluid Accessories
  • Flow Rate : 130 l/min
  • Ratio : 1:1
  • Max Pressure : 8 Bar
  • Max Cicles For Minute : 270 cpm
  • Delivery For Cicles : 0,540 l
  • Max Suction Lift : Dry Column 5 M - Wet Column 7,5 M
  • Max Size Pumpable Solids : 3 mm
  • Max Working Temperature : 65 °C
  • Noise Level : 78 dB
  • Max Air Consumption : 1,1 m3/Min
  • Air Working Pressure : 3 - 8 Bar
  • Air Inlet Connection : G 3/8" (F)
  • Air Outlet Connection (Muffler) : G ¾" (F)
  • Fluid Inlet Connection : G 1¼" (F)
  • Fluid Outlet Connection : G 1" (F)
  • Balls For Inlet : Ball Valve
  • Membranes : Ptfe+Hytrel®
  • Balls : Ptfe
  • Seats : AISI 316 Stainless Steel
  • Packing : No. 1 - 0,03 m3
  • Gross Weight : 24 Kg
  • Areas of Use : Aeronautics, Agriculture, Automotive, Cleaning, Building and Road Construction, Chemical Industry, Manufacturing Industry, Mining Industry, Lube Trucks and Transports, Shipping and offshore, Railway Transport
  • Warranty : 12 Months
